Product Details:
|
| Model Number: | S750 Military Thermal Binoculars | Detector Type:: | Un-cooled FPA Micro-bolometer |
|---|---|---|---|
| Resolution: | 640×480，384x288 | Spatial Resolution:: | 0.47mrad |
| FOV: | 10.8°x8.3°/5.4°x4.1°(optional) | NETD: | ≤60mk@30℃ |
| Frame Frequency: | 50Hz | Spectral Range: | 8-14um |
| High Light: | Uncooled thermal binoculars military,Infrared thermal binoculars military,Long Distance thermal Binoculars |
||
Military Style Thermal Imaging Binoculars Infrared For Long Range Distance
Parameter:
| Item | S750 | S750-640 | ||
| Detector | Type | Uncooled FPA | ||
| Spectral range | 8 - 14 µm | |||
| Resolution | 384×288 | 640×480 | ||
| Frame rate | 50Hz | |||
| FOV | 10.8°×8.3°/5.4°×4.1°(extendable) |
12.5°×9.4°/6.2°×4.7° (extendable) |
||
| NETD | ≤60mk@30℃ | |||
| Focus | Auto / Motorized focus | |||
| Display | Screen | HD OLED binocular screen,800×600 | ||
| Polarity | White-hot / black-hot | |||
| CCD | Imager | 1/3＂CCD,pixel 795(H)×596(V) | ||
| FOV | 10.8°×8.3° | |||
| Storage | Memory | Internal memory | ||
| Storage method | Picture taking/video recording | |||
| File format | BMP/AVI | |||
| Capacity | Over 10 thousand photos or 4 hours of video | |||
| Settings | Brightness/gain | Auto/manual | ||
| Color palettes | Black-hot / white-hot | |||
| Digital zoom | x 2,X3, x 4 | |||
| Enhancement | Yes | |||
| Image filtering | Yes | |||
| Power supply | Battery type | Rechargeable Li-ion battery | ||
| Operating time | >5 hours | |||
| Charging | Dedicated charger | |||
| Environment | Working temp. | -30℃～50℃ | ||
| Storage temp. | -40℃～60℃ | |||
| Humidity | ≦90％(Non-condensing) | |||
| Protection class | IP67 | |||
| Dimension & weight | Weight | ≤1.4Kg | ||
| housing color | Black(standard) | |||
| Dimension | 210(L)mm×195(W)mm× 85(H)mm | |||
| Interface | External power | Yes | ||
| Video output | PAL | |||
| USB port | Yes | |||
| Installation interface | 1/4"-20-UNC | |||
| Detection distance |
Human(1.7x0.5)m |
1650m(standard lens)/3300m(optional lens) | 2400m(standard lens)/4800m(optional lens) | |
| Car(2.3×2.3)m | 2300m(standard lens)/4600m(optional lens) | 3300m(standard lens)/6700m(optional lens) | ||
| Recognition distance | Human(1.7×0.5)m | 550m(standard lens)/1100m(optional lens) | 800m(standard lens)/1600m(optional lens) | |
| Car(2.3×2.3)m | 760m(standard lens)/1520m(optional lens) | 1100m(standard lens)/2200m(optional lens) | ||
Features:
