Product Details:
|
| Type: | Multifunctional Fusion Military Thermal Binoculars | Focus: | 50mm |
|---|---|---|---|
| Fov: | 12.4°×7° | Resolutions: | 640x512 |
| Spectral Range: | 8 - 14 µm | Frame Rate: | 50Hz |
| Zoom: | 1~4X | Degree Of Protection: | IP67 |
| High Light: | Fusion thermal binoculars military,Multifunctional binoculars thermal,military thermal binoculars Multifunctional |
||
Multifunctional Fusion Military Thermal Binoculars Night Vision With GPS Positioning WIFI Electronic Compass
Parameter:
| Infrared Observation Distance | |||
| Reference | Man(1.8x0.5m) | Car(2.3x2.3m) | |
| Detect | 1470m | 4510m | |
| Discern | 368m | 1128m | |
| Identify | 184m | 564m | |
| Infrared Lens | |||
| Focus | 50mm | ||
| Fov | 12.4°×7° | ||
| Infrared Sensors | |||
| Detector type | Uncooled infrared focal plane | ||
| Resolutions | 640x512 | ||
| Spectral range | 8 - 14 µm | ||
| Frame rate | 50Hz | ||
| Zoom | 1~4X | ||
| Low Light Observation Distance | |||
| Illuminance | 10 -1 lx | 10 -2 lx | 10 -3 lx |
| Detect | 1470m | 1200m | 980m |
| Discern | 368m | 300m | 254m |
| Identify | 184m | 160m | 130m |
| Low Light Lens | |||
| Focus | 35mm | ||
| Fov | 12.4°×7° | ||
| Sensor type | CMOS Sensor | ||
| Low light Detector | |||
| Type | 6um | ||
| Pixels | 1280x720 | ||
| Dynamic Range | 76DB | ||
| Frequency | 50Hz | ||
| Signal to noise ratio | Illuminance 10 -1 lx | Illuminance 10 -2 lx | Illuminance 10 -3 lx |
| Signal to noise | 60db | 55db | 45db |
| Image Display | |||
| Mode | OLED HD binocular display | ||
| Resolution | 1024x768 | ||
| Colors | White heat / black heat / low light / fusion/picture-in-picture display / fusion color /fusion gray / fusion black and white | ||
| Storage | |||
| Built-in storage | 16G | ||
| Video format | AVI | ||
| Physical characteristics | |||
| Working time | 5 hours | ||
| Total weight | 1.3kg(without battery) | ||
| Size | 182.5mmX180.2mmX82.8mm(LxWxH) | ||
| Interface | |||
| Power in | DC12V | ||
| Video output | PAL | ||
| Data interface | USB2.0 | ||
| Control interface | RS232 | ||
| Environmental indicators | |||
| Work Temperature | -40℃~+55℃ | ||
| Storage temperature | -50℃~+60℃ | ||
| Humidity | less than 90% | ||
| Degree of protection | IP67 | ||
| Other | |||
| Optional Function | GPS/WIFI | ||
| Compass | Azimuth accuracy 1° Pitch angle accuracy1° | ||
Features:
1. The observed target is more obvious, which is beneficial to detect the target faster and more accurately under the background of concealed camouflage. The use of image fusion color night vision mode is particularly prominent;
2. The observed image is more natural and more in line with the habits of the human eye, which can significantly improve the target recognition performance of the human eye and reduce fatigue;
3. It has the advantages of low-light and thermal imaging at the same time, and there are a variety of observation modes to choose from, which can better meet the observation needs of different scenes and different people;
4. The observed information is more abundant, the details are more perfect, the scene is easier to understand, and the effective detection and recognition distance is longer;
5. To meet the needs of all-weather combat, it can be observed and used in the dark, in a completely dark and closed environment and in bad weather conditions;
6. Small size, light weight, comfortable and convenient to use, long continuous working time and good environmental adaptability.
